Direct Diode Sources - Single Array

Key Features

Small form factor for flexibility
High power (up to 50 kW) with high efficiencies (>60%)
Custom beam geometries
Homogenization options available
Multi-wavelength options
Modular design
Rugged design for use in harsh environments
System-level integration possible

		760 nm – 1100 nm				1400 nm - 1700 nm
Parameter	Unit	Typical Value @ 25°C
Power	W	1,920	2,400	2,880	50,000	600
Bar Length	mm	10
Oper. Mode	-	CW			pulsed	CW
Current	A	90	105	125	1,100	35
# of Bars	-	≤ 24			≤ 50	≤ 24
Voltage/Bar	V	1.9 (760 nm - 830 nm) 1.7 (850 nm - 1100 nm)			2 1.8	1.5
Size FA	mm	28.4
Size SA	mm	11.5
Mass	g	40

Plastic welding
Automated Fiber Placement (AFP) for composite materials
Thermal annealing
Solar cell manufacturing
Metal additive manufacturing
Food packaging
Compact and targeted heating sources
Pump source for high peak power laser systems
